Stainless Steel 410 Sheet
Table of Content - SS 410 Sheets Specification And Grade - AISI 410 Plate Chemical Structure - Stainless Steel 410 Plates Mechanical Behaviour - Basic Types Of Stainless Steel 410 Sheet - SS UNS S41000 Plates Equivalent Grades - 410 Stainless Steel Plates Physical Properties
SS 410 Sheets Specification And Grade
| Specifications | ASTM A240 / ASME SA240 |
| Length | 2000 milimeter, 2440 milimeter, 3000 milimeter, 5800 milimeter, 6000 milimeter, etc |
| Thickness | 4 milimeter - 100 milimeter |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Width |
1000 milimeter, 1219 milimeter, 1500 milimeter, 1800 milimeter, 2000 milimeter, 2500 milimeter, 3000 milimeter, 3500 milimeter, etc |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
Standards Dimensions Of SS 410 Circle, Buy 410 Stainless Steel 2B Plate At Low Price, SS UNS S41000 Plates Specification.
AISI 410 Plate Chemical Structure
| Grade | S | C | Cr | Mn | N | Si | Ni | P | Mo |
| SS 410 | 0.030 max | 0.15 max | 11.5 – 13.5 | 1.0 max | – | 1.0 max | 0.50 max | 0.040 max | – |
Stainless Steel 410 Plates Mechanical Behaviour
Stainless Steel 410 Shim Sheets Range, Check SS 410 Coils Chemical Composition, AISI 410 Plate Mechanical properties, Call Now to Get 410 Stainless Steel Plates Free sample.
| Grade | Hardness (Brinell) MAX | Tensile Strength | Elongation | Yield Strength | Hardness (Rockwell B) MAX |
| 410 | 217 | 65 (450) | 20 | 30 (205) | 96 |
Basic Types Of Stainless Steel 410 Sheet
SS UNS S41000 Plates Equivalent Grades
Accept all small/ Large Orders SUS 410 Plate, Weight Chart Of 410 Stainless Steel Hot Rolled Plates, View ASTM A240 Stainless Steel 410 Shim Sheets Grades Equivalent.
| STANDARD | BS | WERKSTOFF NR. | GOST | UNS | AFNOR | JIS | EN |
| SS 410 | 410S21 | 1.4006 | – | S41000 | – | SUS 410 | X12Cr13 |
410 Stainless Steel Plates Physical Properties
Buy Stainless Steel 410 Cold Rolled Plates, SS 410 Perforated Sheets Certified & Tested Materials, We provide Multiple Payment Options Of SS Grade 410 Polished Plates, Physical Properties Of Stainless Steel 410 Sheet.
| Grade | Specific Heat 0-100°C (J/kg.K) |
Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) |
Thermal Conductivity (W/m.K) |
Electrical Resistivity (nΩ.m) | |||
| 0-315°C | 0-100°C | 0-538°C | at 500°C | at 100°C | |||||
| 410 | 460 | 7800 | 200 | 11 | 9.9 | 11.5 | 28.7 | 24.9 | 570 |
