Pipe Elbow
Long Radius Elbows, Short Radius Elbow, Carbon Steel Elbows, Stainless Steel Elbow
Manufacturer
A234 Wpb, A420 Wpl6, A234 Wp11, A234 Wp5, A403 Wp304l, A403 Wp316l | Asme/ansi B16.9, Ansi
B16.28, Mss-sp-43
Long/short Radius Elbows – 90° Elbow, 45° Elbow, 180° Elbow, 1d, 2d, 3d, 4d, 5d, 10d, Custom
Radius Elbows
Carbon Steel Elbows, Stainless Steel Elbows, Alloy Steel Elbows, Long Radius Elbows, Short
Radius Elbows. 3d Elbows, 5d Elbows, Custom Radius Elbow Supplier In India, 316 Elbow, A234 Wpb
Elbows Manufacturer, A420 Wpl6 Elbow, A234 Wp11 Elbow, A234 Wp5 Elbow, A403 Wp304 Elbow, A403
Wp304l Elbow, A403-wp316 Elbow, A403-wp316l Elbow, Seamless Elbows, Large Diameter Fabricated
Elbows, 20″ Nb Elbow,36″ Nb Elbow Supplier, Buttweld Elbows Manufacturer, Duplex 2205 Pipe
Elbow, 100% X-ray Welded Elbows
| Outside Diameter: | Seamless Elbow ( 1/2″～24″), ERW / Welded / Fabricated Elbow (1/2″～48″) |
| Wall Thickness: | 3mm – 40mm / SCH3, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Bending Radius: | R=1D – 10D, 15D, 20D |
| Product’s Angle: | 5° – 180° Elbows, 90° and 45° Long Radius Elbows, Long Radius Returns, Short Radius Elbows and Returns |
| Value Added Services: | Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering |
| Production Grades: | Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Cupro Nickel |
Pipe Elbow Material Grades -
Stainless Steel Elbow Astm A403 Wp Gr. 304, 304h, 309, 310, 316, 316l, 317l, 321, 347, 904l
Carbon Steel Elbow Astm A 234 Wpb , Wpbw, Wphy 42, Wphy 46, Wphy 52, Wph 60, Wphy 65 & Wphy 70.
Low Temperature Carbon Steel Elbow Astm A420 Wpl3, A420 Wpl6
Alloy Steel Elbow Astm / Asme A/sa 234 Gr. Wp 1, Wp 5, Wp 9, Wp 11, Wp 12, Wp 22, Wp 91
Duplex Steel Elbow Astm A 815, Asme Sa 815 Uns No S31803, S32205. Werkstoff No. 1.4462
Nickel Alloy Elbow Astm / Asme Sb 336 Uns 2200 ( Nickel 200 ), Uns 2201 (Nickel 201 ), Uns 4400 (Monel 400 ), Uns 8020 ( Alloy 20 / 20 Cb 3, Uns 8825 Inconel (825), Uns 6600 (Inconel 600 ), Uns 6601 ( Inconel 601 ), Uns 6625 (Inconel 625), Uns 10276 ( Hastelloy C 276 )
| Nominal Bore | Outside Diameter | Light (A-Class) Thickness Weight | Medium (B-Class) Thickness Weight | Heavy (C-Class) Thickness Weight | |||||
|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | mm | kg/mtr | mm | kg/mtr | mm | kg/mtr |
| 1/8" | 3 mm | 0.406 | 10.32 | 1.80 | 0.361 | 2.00 | 0.407 | 2.65 | 0.493 |
| 1/4" | 6 mm | 0.532 | 13.49 | 1.80 | 0.517 | 2.35 | 0.650 | 2.90 | 0.769 |
| 3/8" | 10 mm | 0.872 | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.02 |
| 1/2" | 15 mm | 0.844 | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.45 |
| 3/4" | 20 mm | 1.094 | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.90 |
| 1" | 25 mm | 1.312 | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.97 |
| 1.1/4" | 32 mm | 1.656 | 42.90 | 2.65 | 2.580 | 3.25 | 3.140 | 4.05 | 3.84 |
| 1.1/2" | 40 mm | 1.906 | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.43 |
| 2" | 50 mm | 2.375 | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.17 |
| 2.1/2" | 65 mm | 3.004 | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.90 |
| 3" | 80 mm | 3.500 | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.1 |
| 4" | 100 mm | 4.500 | 114.30 | 3.65 | 9.890 | 4.50 | 12.10 | 5.40 | 14.4 |
| 5" | 125 mm | 5.500 | 139.70 | - | - | 4.85 | 16.20 | 5.40 | 17.8 |
| 6" | 150 mm | 6.500 | 165.10 | - | - | 4.85 | 19.20 | 5.40 | 21.2 |
